TC5V Valve Gate Controller
Overview
- The TC5V Valve Controller supports various input signals, including 110Vac, 230Vac, 24Vdc, switch type. Similarly, the output mode can also be selected as 110Vac, 230Vac, 24Vdc, Relay(max:2A).
- The valve controller's time display function can be adjusted to the first decimal place and provides a time counting function that allows selecting either cumulative or countdown timing. It also offers the option of a pressure-maintaining mode to ensure valve stability.
| TC5V | Module |
|
Display |
7-segment LED 0.4*4*2 |
|
Input Power |
230Vac±10%, 50/60Hz |
|
Trigger Voltage |
(Must jump JP), 110Vac(50/60Hz), 230Vac(50/60Hz), 24Vdc, switch(24Vdc) |
|
Output Power |
(Must jump JP), 110Vac/230Vac/24Vdc/Relay(Max: 2A) |
|
Keys |
5 keys: select/confirm, manual output, plus, minus, time setting |
|
Function Display Lamps |
A/B mode lamp, OPEN lamp, SIGNAL lamp, pressure retaining lamp, manual output lamp |
